Changzhou Cewoo Equipment Co.,Ltd
| Payment Type: | T/T |
| Min. Order: | 1 Piece/Pieces |
Type: Roller
Structure: Spherical
Applicable Industries: Machinery Repair Shops, Retail, Construction works
Brand Name: UKL
Model Number: BS2-2205-2RS/VT143
Precision Rating: P0 P6 P5 P4 P2
Seals Type: opened
Number Of Row: Double Row
Product Name: Special Roller Bearing
Material: Chrome Steel
Application: Mining. Metallurgy. Agriculture. Chemical
Cage: Steel Cage, Brass Cage
Package: Single Box
Service: Guarantee
Feature: Low Noise. Long Life high
MOQ: 100 Pcs
Main Market: Global
Place Of Origin: Jiangsu, China, CHINA
| Selling Units | : | piece |
| Package Type | : | The economic plastic tube and commericail package |
Product name | Mass Stock Sealed Spherical roller bearing BS2-2205-2CS 2RS/VT143 | ||
Bearing Type | Spherical Roller Bearing | ||
Bearing Material | Chrome steel | ||
Bearing Cage | Steel Cage, Brass Cage | ||
ID*OD*W(mm) | 25x52x23mm | ||
Net weight(kg) | 0.26KG | ||
Quality Certificate | ISO9001:2008 | ||
Feature | Low noise, less vibration, high precision and long life | ||
Brand name | UKL | ||
Tolerance level | ABEC-1 (P0), ABEC-3 (P6)ABEC-5,ABEC-7,ABEC-9 | ||
Seals type | open | ||
Precision rating | P0 P6 P5 P4 | ||
Antirust period | Bearings should normally be put under the protected condition then it is to be stored and preserved. The rustresisting period is two years. | ||
Application | Mining operations, paper mills, oil fields, marine industry, steel, electrical, construction machinery, various kinds of professional machinery and heavy industry of all types. | ||
Models of Spherical Roller Bearing(If you don`t find the model you need, pls contact us.)
Model No. | d[mm] | D[mm] | B[mm] | C[kN] | C0[kN] | m[kg] |
22205/20 E | 20 | 52 | 18 | 44.91 | 39.6 | 0.28 |
21305 CC | 25 | 62 | 17 | 44.19 | 37.35 | 0.27 |
22205 E | 25 | 52 | 18 | 44.91 | 39.6 | 0.18 |
22205 EK | 25 | 52 | 18 | 44.91 | 39.6 | 0.17 |
BS2-2205-2RS/VT143 | 25 | 52 | 23 | 44.91 | 39.6 | 0.26 |
21306 CC | 30 | 72 | 19 | 59.13 | 54.9 | 0.41 |
22206 E | 30 | 62 | 20 | 59.49 | 54 | 0.28 |
22206 EK | 30 | 62 | 20 | 59.49 | 54 | 0.28 |
BS2-2206-2RS/VT143 | 30 | 62 | 25 | 59.49 | 54 | 0.34 |
21307 CC | 35 | 80 | 21 | 71.28 | 64.8 | 0.54 |
22207 E | 35 | 72 | 23 | 79.92 | 76.5 | 0.44 |
22207 EK | 35 | 72 | 23 | 79.92 | 76.5 | 0.43 |
BS2-2207-2RS/VT143 | 35 | 72 | 28 | 79.92 | 76.5 | 0.52 |
21308 E | 40 | 90 | 23 | 96.3 | 97.2 | 0.74 |
21308 EK | 40 | 90 | 23 | 96.3 | 97.2 | 0.74 |
22208 E | 40 | 80 | 23 | 88.65 | 81 | 0.53 |
22208 EK | 40 | 80 | 23 | 88.65 | 81 | 0.52 |
22308 E | 40 | 90 | 33 | 139.5 | 126 | 1 |
22308 E/VA405 | 40 | 90 | 33 | 139.5 | 126 | 1.05 |
22308 EK | 40 | 90 | 33 | 139.5 | 126 | 0.99 |
BS2-2208-2RS/VT143 | 40 | 80 | 28 | 88.65 | 81 | 0.57 |
BS2-2208-2RSK/VT143 | 40 | 80 | 28 | 88.65 | 81 | 0.55 |
BS2-2308-2RS/VT143 | 40 | 90 | 38 | 139.5 | 126 | 1.2 |
21309 E | 45 | 100 | 25 | 116.1 | 114.3 | 0.98 |
21309 EK | 45 | 100 | 25 | 116.1 | 114.3 | 0.97 |
22209 E | 45 | 85 | 23 | 93.6 | 88.2 | 0.57 |
22209 EK | 45 | 85 | 23 | 93.6 | 88.2 | 0.56 |
22309 E | 45 | 100 | 36 | 171 | 164.7 | 1.4 |
22309 E/VA405 | 45 | 100 | 36 | 171 | 164.7 | 1.4 |
22309 EK | 45 | 100 | 36 | 171 | 164.7 | 1.35 |
BS2-2209-2RS/VT143 | 45 | 85 | 28 | 93.6 | 88.2 | 0.66 |
BS2-2209-2RSK/VT143 | 45 | 85 | 28 | 93.6 | 88.2 | 0.66 |
BS2-2309-2RS/VT143 | 45 | 100 | 42 | 171 | 164.7 | 1.6 |
Spherical Roller Bearings Series
Spherical roller bearings have two rows of rollers with a common sphere raceway in the outer ring and two inner ring raceways inclined at an angle to the bearing axis.
This gives them an attractive combination of design features making them irreplaceable in many demanding applications. They are self-aligning and consequently insensitive to misalignment of the shaft relative to the housing and to shaft deflection or bending.
1. Material of ring : GCr15,
2.Material of Cage: Steel, brass, polyamide, nylon
3.Material of Roller: chromium steel
Internal Structure and Retainer Material Variation
C: Symmetrical roller, Stamped Steel retainer
CA: Symmetrical roller, one-pice brass cage
CTN1: Symmetrical roller, nylon cage
E: Third generation design. improved stress distribution; offer much longer service life than normal designs
Q: Bronze cage
MB: Symmetrical roller,Two-pice brass cage
EM: Symmetrical roller, Special alloy Integral cage.
K: Tapered bore bearing,taper is 1:12
K30: Tapered bore bearing,taper is 1:30
N: A snap ring groove on the outer ring
W33: There are three lubrication groove and three lubrication holes in the outer ring
C0:Norminal clearance,omitted in destination
C2:Less than Norminal clearance
C3:Larger clearance than C0
C4: Larger clearance than C3
